工厂模式

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36

class ISplitter{
public:
    virtual void split()=0;
    virtual ~ISplitter(){}
};

class BinarySplitter : public ISplitter{

};

class TxtSplitter: public ISplitter{

};

class PictureSplitter: public ISplitter{

};

class VideoSplitter: public ISplitter{

};

class MainForm : public Form
{
    TextBox* txtFilePath;
    TextBox* txtFileNumber;
    ProgressBar* progressBar;

public:
    void Button1_Click(){

        ISplitter * splitter=
            new BinarySplitter();//依赖具体类
    splitter->split();
    }
};

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144

#include <iostream>
#include <memory> // 引入智能指针

// 为了让代码能编译，定义一个空的 Form 类
class Form {};

// =================================================================
// 1. 抽象产品 (Abstract Product)
//    定义了工厂方法所创建的对象的接口。
// =================================================================
class ISplitter {
public:
    virtual void split() = 0;
    virtual ~ISplitter() { std::cout << "ISplitter destructor called." << std::endl; }
};

// =================================================================
// 2. 具体产品 (Concrete Products)
//    实现了 ISplitter 接口。
// =================================================================
class BinarySplitter : public ISplitter {
public:
    void split() override {
        std::cout << "Splitting a BINARY file..." << std::endl;
    }
};

class TxtSplitter : public ISplitter {
public:
    void split() override {
        std::cout << "Splitting a TXT file..." << std::endl;
    }
};

class PictureSplitter : public ISplitter {
public:
    void split() override {
        std::cout << "Splitting a PICTURE file..." << std::endl;
    }
};

class VideoSplitter : public ISplitter {
public:
    void split() override {
        std::cout << "Splitting a VIDEO file..." << std::endl;
    }
};

// =================================================================
// 3. 抽象工厂 (Abstract Factory / Creator)
//    声明了工厂方法，该方法返回一个 ISplitter 类型的对象。
// =================================================================
class SplitterFactory {
public:
    virtual ISplitter* CreateSplitter() = 0; // 这就是“工厂方法”
    virtual ~SplitterFactory() {}
};

// =================================================================
// 4. 具体工厂 (Concrete Factories / Concrete Creators)
//    重写工厂方法以返回一个具体产品的实例。
// =================================================================
class BinarySplitterFactory : public SplitterFactory {
public:
    ISplitter* CreateSplitter() override {
        return new BinarySplitter();
    }
};

class TxtSplitterFactory : public SplitterFactory {
public:
    ISplitter* CreateSplitter() override {
        return new TxtSplitter();
    }
};

class PictureSplitterFactory : public SplitterFactory {
public:
    ISplitter* CreateSplitter() override {
        return new PictureSplitter();
    }
};

class VideoSplitterFactory : public SplitterFactory {
public:
    ISplitter* CreateSplitter() override {
        return new VideoSplitter();
    }
};

// =================================================================
// 5. 客户端 (Client)
//    客户端代码仅依赖于抽象接口（ISplitter 和 SplitterFactory）。
// =================================================================
class MainForm : public Form {
private:
    SplitterFactory* factory; // 持有一个工厂的引用

public:
    // 通过构造函数注入具体的工厂实例
    MainForm(SplitterFactory* fact) : factory(fact) {}

    void Button1_Click() {
        if (!factory) {
            std::cout << "Error: Factory is not set!" << std::endl;
            return;
        }

        // 多态创建：具体创建哪个 Splitter 由 factory 的类型决定
        ISplitter* splitter = factory->CreateSplitter();

        splitter->split();

        // 重要：必须手动释放内存，否则会造成内存泄漏！
        delete splitter;
        splitter = nullptr;
    }
};

// =================================================================
// 示例用法
// =================================================================
void RunExample() {
    // 场景1：主窗口需要处理文本文件
    SplitterFactory* txtFactory = new TxtSplitterFactory();
    MainForm txtMainForm(txtFactory);
    std::cout << "--- Text Form Simulation ---" << std::endl;
    txtMainForm.Button1_Click();
    delete txtFactory; // 清理工厂

    std::cout << "\n----------------------------\n" << std::endl;

    // 场景2：主窗口需要处理视频文件
    SplitterFactory* videoFactory = new VideoSplitterFactory();
    MainForm videoMainForm(videoFactory);
    std::cout << "--- Video Form Simulation ---" << std::endl;
    videoMainForm.Button1_Click();
    delete videoFactory; // 清理工厂
}

int main() {
    RunExample();
    return 0;
}
